Block Clamp

Block Clamp

Block Clamp is an industrial equipment used to handle square and rectangular block objects. It usually consists of two jigs that can grip two opposite faces of an object and then lift or rotate it up and down. Block Clamps are usually built of steel and can carry very heavy objects. They are widely used in industries such as construction, manufacturing, logistics, and shipping, and can be used to handle hard and bulky objects such as slate, concrete blocks, wood boards, etc. They are efficient and safe solutions that reduce the need for labor, increase productivity and reduce risk while working.

The clamp is a forklift attachment that includes a frame, an arm connected to the frame and a cylinder connected to the arm. Holding arm includes left and right arms. One end of the cylinder is hinged with the left arm, and the other end of the cylinder is hinged with the right arm. The left arm and the right arm are controlled to open and close by the oil cylinder. At least one first limit hole is arranged on the left of the hinge point on the first connector, and the second connector is provided with at least one first limiting hole on the right of the hinge point. The first limiting hole is inserted with a first limiting component for limiting the closing angle of the left arm and the right arm, which so as to limit the minimum clamp angle of the clamp and prevent the collision of the left  arm and the right arm. There is a first limit hole in the holding clamp, which can limit the closing angle of the left arm and the right arm so as to limit the minimum clamping angle of the clamp and prevent the collision of the left and the right arm. Then it can clamp smaller objects. The structure is simple, easy to operate, and has strong practicality.

Advantage design:

There is provided with a first limit hole in the liquid transmission. It can limit the closing angle of left arm and the right arm, thus playing the role of limiting the minimum clamping angle of the clamp, preventing the collision of the left arm and right arm, but also clamping smaller objects.Liquid transmission structure is simple, easy to operate, and has strong practicality. And it can be convenient to load large items and install small items, and can prevent the clamp arm from colliding.

Technical Capacity:

Model		Loading	Dimension	Arm size		Open size	Weight
		kg	A1xA2	mm		mm	kg	L（mm）	C1（mm）	C2（mm）
UN15A-E16C		1500	1130×1350	1000x240		260-1600	705	241	405	578
UN15B-E16C		1500	1130×1350	1000x241		260-1600	705	241	405	578
UN15B-E18C		1500	1330×1350	1200X240		260-1600	750	241	410	580
UN15B-E19C		1500	1530×1350	1400X300		260-1600	810	241	414	583
UN20A-E16C		2000	1132×1350	1000X240		260-1600	805	243	408	580
UN20B-E16C		2000	1132×1350	1000X240		260-1600	805	243	408	580
UN20B-E16D		2000	1332×1350	1200X240		260-1600	850	243	413	582
UN20B-E16F		2000	1532×1350	1400X3000		260-1600	910	243	417	585
UN25A-E16C		2500	1133×1350	1000X240		260-1600	870	248	410	581
UN25B-E16C		2500	1133×1350	1000X240		260-1600	870	248	410	581
UN25B-E16D		2500	1333×1350	1200X240		260-1600	920	248	415	583
UN25B-E16F		2500	1533×1350	1400X300		260-1600	975	248	419	586
