Precast Drain Mould

Precast Drain Mould

Precast Drain Mould is a prefabricated mold used in the construction industry, mainly used in the production of concrete drainage systems, including underground stormwater drainage systems, sewage drainage systems, drainage ditches, equipment sinks, etc. The mold can be customized with prefabricated parts of different shapes and sizes to suit different project needs.

Precast Drain Mould is made of high-quality steel, which is corrosion-resistant, durable, and easy to clean. The use of this mold can effectively improve the production efficiency of prefabricated components, reduce construction costs, and at the same time can ensure the quality and accuracy of prefabricated components.

Precast Drain Mould can also automate the production of prefabricated components, which can further improve production efficiency and reduce manpower input. In addition, the use of this mold can also reduce the time and cost of concrete pouring on the construction site, thereby shortening the overall construction period.

The specifications and dimensions of Precast drain mould can be customized. The rain gutter steel mold is welded with 3.5mm steel plate reinforcement and fixed with a snap button, which is convenient for assembly and disassembly. How to use rain gutter steel mold: first spray a layer of engine oil and mold release agent inside the rain gutter mold to facilitate mold removal, and then pour the mixed cement or concrete into the mold, and vibrate and form by a vibrating platform or vibrating rod, etc. After the initial solidification of cement, it can be demoulded, about 24 hours.

The concrete prefabricated Precast Drain Mould has complete product specifications and can be customized. Several specifications of the mold box are introduced below:

Square manhole cover mould: 500*600*60; 600*600*65

Rain cover mould: 500*500*60; 300*450*60; 350*500*60; 400*600*55; 450*750*70

Ditch cover mold: 500*320*50; 500*500*60, etc.

Roadside stone mould 1000*250*120; 1000*300*120; 750*380*120; 750*300*120; 750*350*120; 750*250*120

Slope protection molds, color brick molds, color tile molds, etc. are rich in varieties, and there are many specifications and sizes, which can be customized according to drawings.

Precast Drain Mould Main features:

1. High-standard material selection: All are welded with the national standard profiles of large steel plants such as Shangang Group, and the panels are made of specially customized high-finish Q345 manganese steel plates. The surface of the steel plates is of good quality, high dimensional accuracy, wear resistance, mechanical properties and Excellent process performance.

2. Advanced equipment processing: high-precision laser cutting machine, large-scale bending machine, CNC car, planer, digital display boring machine and other equipment.

3. High process standard: all the profiles are processed by sandblasting and rust removal, and the large cast iron platform is used for welding to ensure the size of the drawing and the flatness of the panel surface.

4. Good sealing performance: the joints between the components of the mold are uniform, and the joints are tightly closed after the mold is closed, and are sealed with a special sealing tape.

5. Easy to operate: mold opening and closing adopts quick pull pliers, trapezoidal lead screw and other structures, which are fast, portable, low labor intensity and high efficiency.

The component prefabricated mold is provided with a semi-closed hanging template connected and fixed on the top of the mold body. The semi-closed suspension type template includes a plurality of shear key molds fixed on the plane part of the semi-closed suspension type template, and is suspended on the top of the mold body for forming the shear keys on the top surface of the component. Therefore, the operator can collect and level the component through the gap between the shear keys, so that the prefabricated mold of the component can form the shear key on the top of the component while ensuring that the concrete is poured densely and the surface is flat, effectively improving Dimensional accuracy of components
