Block Making Machine

Model: UNT400

Block making machines are mechanical devices used for producing concrete blocks, which are commonly used in construction projects. These machines use hydraulic pressure to compress sand, gravel, cement, and other materials into solid blocks of varying sizes and shapes. Block making machines come in different types, including manual, semi-automatic, and fully automatic machines.

Send Inquiry

Product Description

For a new concrete products manufacturer, considering the cost and limited capacity customer requires, we have designed smallest QT3-15 type block making machine, which are best choice for someone who has limited budget, limited space and the desire to achieve good quality blocks with the minimum cash outlay.the skeleton of the block making machine is adopted high intensity steel and special craft for welding, It can achieve the most reasonable operation speed,the most accurate deceleration and orientation.

Manual block making machines require more labor input, as they have to be operated by hand. Semi-automatic machines have some automated features, such as feeding mortar and removing finished blocks, but require some manual adjustments. Fully automatic machines are highly automated and require minimal manual input, making them the most efficient type.

The production capacity of block making machines varies from small-scale machines capable of producing a few blocks per hour to large-scale machines that can produce thousands of blocks per hour. These machines are commonly used in the construction industry for building walls, foundations, and other structures.

Main features:

1. Lowest maintenance cost and easiest operation
2. Imported well-known brand intelligence PLC and electrical element
3. Simple horizontal secondary material feeding, is combined both pressing and vibrating to ensure the high compactness and performance

Technical specifications:

Overall dimension	2750×1800×2600mm	Vibration method	Synchronous mode of table & mould
Pallet size	700×540×18-25mm	Vibration frequency	50-70Hz
Working area	670×500mm	Machine power	49.03kW
Machine weight	5500kg	Cycle time	15s-20s depending on the product size

Production Capacity

Specification of products (mm)		Number of blocks per pallet	Pieces/ hour	Pieces/8 hours
Block	400×200×200	3	540	4,320
Hollow Block	400×100×200	5	900	7,200
Interlock Paver	225×112.5×60	10	2,400	19,200
Rectangular Paver	200×100×60/80	12	2,880	23,040

Hollow Block Machine is a specialized equipment used in the construction industry for the production of hollow blocks. The machine works by compacting cement, sand, and other materials into molds that are then left to dry and cure. The blocks produced by the machine are lightweight, durable, and perfect for constructing walls, fences, and other structures.

The benefits of Hollow Block Machine are numerous. First, they are cost-effective, as they can produce a large number of blocks in a short time, thereby reducing labor costs. Secondly, they are versatile and can be used for a wide range of construction projects. Finally, they are durable and can withstand harsh weather conditions and natural disasters.

In addition to its benefits, the Hollow Block Machine also requires minimal maintenance, which makes it easy for operators to use and maintain. However, it is essential to ensure that the machine is serviced regularly to prevent breakdowns and ensure efficient operation.

Overall, the Hollow Block Machine is an essential tool for any construction project. Its ability to produce quality, lightweight, and durable blocks makes it an ideal choice for construction projects of all sizes.
