Block Making Machinery Equipment

Block making machinery equipment refers to machines used for the production of various types of blocks, such as concrete blocks, cement blocks, interlocking blocks, hollow blocks, solid blocks and more. This equipment can be used for both large-scale commercial production and small-scale production for personal use.

Block Making Machinery Equipment

Block making machinery equipment refers to machines used for the production of various types of blocks, such as concrete blocks, cement blocks, interlocking blocks, hollow blocks, solid blocks and more. This equipment can be used for both large-scale commercial production and small-scale production for personal use.

Block making machinery typically includes a mixer, a vibrating table, a block/paver machine, and a curing chamber. The mixer is used to combine raw materials such as cement, sand, and water to make the base material for the blocks. The vibrating table is used to vibrate and compact the concrete mixture into the desired shape and size of the block. The block/paver machine is then used to mold the compacted mixture into the final block shape. Finally, the curing chamber is used to allow the block to set and dry.

There are different types of block making machinery equipment available, ranging from manual to semi-automatic and fully automatic machines. The choice of machine depends on the scale of production, the types of blocks required, and the available budget.



Frame structure: It is made of high-strength steel and special welding process, and it is sturdy.

Guide column: Made of super-strength special steel, chrome plating has good bending and wear resistance.

Tamper head: Electro-hydraulic synchronous drive, the same pallet product height error is very small, product consistency is good.

Distributing device: Using sensing and hydraulic proportional drive technology, under the action of the swing-type feeding car and the broken arch mechanism, it produces forced centrifugal discharge, and the material is quickly and evenly distributed, which is particularly advantageous for thin-walled multi-row hole products.

Control system: With powerful self-diagnosis and guidance functions, can monitor and display operating status at real time, found faults and timely shutdown and alarm.

The control system has an intelligent action interlock function to prevent misoperation and produce mechanical failure.

Use imported PLC programmable controller, color touch screen, more user-friendly operation interface, parameter guidance and many other practical functions to allow users to easily realize human-machine dialogue.

Vibrators: Driven by electro-hydraulic technology, multi-source vibration system, under the control of the computer by the hydraulic drive to generate vertical synchronous vibration, adjustable frequency, to achieve low-frequency feeding, high-frequency molding working principle, can be good for different raw materials Vibrating effect, vibration speed up to 5g or more.

Rack and pinion type synchronization mechanism: Make sure the block height is the same.

Storage and material distribution device: The supply of materials is controlled by computer to prevent the material from being affected by external factors and to generate internal pressure, to ensure that the material is uniformly distributed, and to minimize the intensity of the product.

Hydraform Block Making Machine

Hydraform Block Making Machine


Technical specification:

Dimension

Rating pressures

Vibration

Vibration frequency

Pallet size

Cycle time

Power

Weight

3100×1680×2400mm

25Mpa

Table Vibration

3800-4500r/min

850×680mm

15-20sec

42.15kw

7400kg


Production Capacity:

Items

Size(L×W×H)

Pcs./mould

Pcs./hour

Pcs./hour

One year(300days)Production

Hollow Blocks

390×190×190

6

1440

11520

3456000

Perforated Blocks

240×115×90

15

3600

28800

8640000

Solid Blocks

240×115×50

30

7200

57600

17280000

Rectangular pavers

200×100×60

21

5040

40320

12096000



Hydraform Block Making Machine

Hydraform Block Making Machine

Why choose unik?

1.Advanced equipment technology

2.fully automated operation

3.Raw materials are widely used.

4.There are various types of machine that cater to different requirements

5.After-sales service is perfect will save you much trouble during production
