Brick Making Production Lines

brick making production lines



Brick making production lines refer to the equipment and machines that are used for the production of bricks. These lines typically include equipment such as mixers, crushers, conveyors, moulds, and brick-making machines. The production process involves mixing and molding various materials, usually including clay or shale, along with additives like sand and water, to create bricks of different shapes and sizes.

Once the raw materials are mixed into a homogeneous clay mixture, it is pushed through a mould machine to form the desired shape. The bricks are then dried and hardened in a kiln, which bakes them at high temperatures to increase their strength and durability.

With brick making production lines, it is possible to produce a large volume of high-quality bricks efficiently and effectively. They are used by manufacturers and suppliers of bricks for building construction, landscaping, and even decorative purposes. Additionally, brick making production lines can be customized to produce various types of bricks, such as interlocking bricks or compressed bricks, depending on specific customer needs.

brick making production lines Products Description

brick making production lines are steadily increasing in popularity in Lagos due to their efficiency and cost-effectiveness. A concrete block is a precast solid block that is used in constructing buildings, roads, and other structures. They are preferred over traditional bricks because they are more durable, fire-resistant, and require less maintenance.We are offering varying models and sizes. These machines produce different shapes and sizes of concrete blocks, depending on the mold used.Investing in a concrete block making machine allows entrepreneurs to produce blocks on-site, eliminating the need for outsourcing from other manufacturers. This enables them to have the flexibility of producing a wide variety of blocks based on customer needs and specifications. The entrepreneurs can also adjust the size, color, and texture of the blocks to suit the construction needs of their customers.

Unique vibration system

Ensure the accuracy of the supply, reduce the density of the density under the action of the internal pressure and other external causes, affect the amount of supply, ensure that the material is used as an ingredient, and the amount of the product density is consistent. good. In addition, it can effectively reduce the work noise, avoid the transmission of vibration power to the rack, and extend the service life of the host.

Advanced electronic components

Similarly, the Siemens electronic components we use in our machines are known for their reliability and stability. These components, including advanced PLCs and other critical subsystems, help ensure that our machines can operate at peak efficiency and quality, no matter the demands of the project or the environment.

Advanced control system

The device, electricity, liquid linkage, PLC control, safe and reliable operation, the main console computer interface operation (Chinese/English menu, LCD touch screen), which can realize the parameter settings of the machine, random signal collection, fault diagnosis analysis，The platform is adjusted to a good working state.

Long life-time mould

The mold plates are made of high-strength manganese steel and chromium steel. After the most advanced domestic carburizing treatment method, the mold hardness can reach more than 60 degrees, which greatly improves the wear resistance of the mold. Optimized milling strategies and hardening technology ensure the high quality of our mould



Products parameters

Dimension	5900×2040×2900mm
Pallet Size	1100×950×28-35mm
Vibration Frequency	3800-4500 r/min
Hydraulic Pressure	25 mpa
Vibration Force	90 KN
Cycle time	15-25s
Power	63.45kW
Weight	12800kg



Product	Product size	pcs/pallet	pcs/hour	Image
Hollow block	400x200x200mm	10 PCS	1800PCS
Hollow block	400x150x200mm	12 PCS	2160 PCS
Rectangular paver	200x100x60/80mm	36PCS	8640 PCS
Interlocking paver	225x112x60/80mm	24PCS	5760PCS
Kerbstone	200x300x600mm	3PCS	720PCS



A production line can work only 2-3 people. And the concrete block machine is a multi -purpose model. Through the replacement of the mold, we can produce a variety of water -transmitted bricks, hollow bricks, solid bricks and other products with a variety of shapes and specifications.

Product Picture

Our factory

Manufacturing

Delivery

workshop

Process

Founded in 2010, UNIK is a manufacturer of concrete brick making machinery and equipment. UNIK pursues the ultimate and continuously innovative development of each product and even a small component of each product. The company has always focused on the development, production, and technical services of environmental protection waste technology and intelligent brick -free brick machines in 12 years to build, production, and technical services for users to build High -level green and environmentally friendly new building materials factories provide all -round technical support, high -end sets of brick -free brick machine equipment, and integrated implementation planning implementation plan.As always, the company will adhere to the research and development of core technology, cultivate professional scientific research talents, and make full use of its own advantages to take the development path of diversified integration and integrated services. UNIK will organize product production and new product development in a timely manner according to the changes in market demand, and continuously improve the integrated solution and content of the operating service, so as to realize the commercialization of scientific and technological innovation and the high value -added of the industrial chain. Development makes greater contributions!
