Small Concrete Brick Machine

Small Concrete Brick Machine Products Description

Features:

▲Perfect combination of German automation technology and system, automatic control, easy operation, low failure rate, high reliability, and has the functions of product formula management and operation data collection.

▲The hydraulic pump valve adopts an international brand, adopts high dynamic proportional valve and constant output pump to adjust speed and pressure, and has the characteristics of high stability, high efficiency and energy saving.

▲The feeding system adopts German technology, which is suitable for the use of special aggregates such as construction waste. The feeding frame, bottom plate and mixing blades are made of high-strength steel, which strengthens the sealing performance, prevents material leakage, ensures long service life, uniform feeding, and improves product quality.

▲With a large number of professional and technical personnel, after years of unremitting efforts, we can meet the different investment needs of users. With exquisite technology and excellent quality, it has won several national patents and its products are spread all over the country.

Products parameters

Dimension	2710×1400×2300mm
Pallet Size	700×540×18-25mm
Vibration Frequency	3800-4500 r/min
Hydraulic Pressure	25 mpa
Vibration Force	68 KN
Cycle time	15-20s
Power	20.55kW
Weight	5500kg



Production capacity:



Product size	Picture	Capacity
400×200×200(mm)		3 pcs/pallet
		540 pcs/hour
225×112×60/80mm		20 pcs/pallet
		2400 pcs/hour
200×100×60/80(mm)		12 pcs/pallet
		2880 pcs/hour
447×298×80/100(mm)		1 pcs/pallet
		180 pcs/hour
Pallet size		700×540㎜
Vibration type		Frequency, amplitude
Excitation frequency		0～65HZ
Power		20.55 kW



Small concrete brick machine also known as concrete block making machine, is a powerful and efficient tool used for producing and forming concrete blocks. These machines are widely used in the construction industry in the Philippines, and they are considered essential equipment for any construction site.These block machines come in different sizes and models, ranging from small manual machines to large fully automatic ones. They can be used to produce a variety of concrete blocks, including hollow blocks, solid blocks, paving blocks, and interlocking blocks.

Use and maintenance of brick machine:

⒈When installing or replacing new or old molds, be sure to avoid collisions and bumps, assemble in a civilized manner, and pay attention to protecting the molds;
⒉ During use, frequently check the size of the mold and the condition of the welding joints. If weld cracks occur, they should be repaired in time. If excessive wear occurs, the aggregate particle size must be adjusted. If excessive wear affects the quality of the product, a new mold must be installed;
⒊ Carefully adjust the gaps, including the spacing between the indenter and the mold core, the indenter and the movement plane of the feeder, and the mold frame and the line plate. Relative movements must not interfere with or cause friction;
⒋When cleaning the mold on a daily basis, use an air compressor and soft tools to remove concrete residues. It is strictly prohibited to hit or pry the mold with gravity;
⒌The replaced mold should be cleaned and oiled to prevent rust. It should be placed flat on a support pad in a dry and flat place to prevent gravity deformation.



Product Picture

Our factory

Manufacturing

Delivery

workshop

Process

It is our aim to protect the central service of pre-sale, sale and after-sales. It has increasingly become the basic requirement of our customers. We have established a strong marketing network integrating sales, service and integration, the company's new products and All kinds of services can reach the market and users in a timely and comprehensive manner, forming a complete product development mechanism and network operation mechanism.

In the sales of products, the interests of customers are our first consideration. Our services are pursuing refinement. From pre-sales consultation, enthusiastic service to sales promotion products, we all require fine and careful. Strong design and development, production and manufacturing, installation and commissioning, technical maintenance, occasional return visits, strict quality assurance and fast after-sales service, each link has been carefully arranged to solve a series of customer worries.

Where the use of our products, the warranty period of one year, our factory can send technicians to the user free installation and commissioning, transfer technology, life-long accessories, to ensure customer satisfaction!

Before the customer purchases, the company will send engineers and technicians to the user site to plan the site and design the best process plan for the user. After the purchase, the company will assign free after-sales service personnel to the site to guide the customer to install and debug, and assist the customer in planning and management. Equipment, until the user is satisfied.

Before sale:
(1) Selection of equipment model.
(2) Design and manufacture products according to the special requirements of customers.
(3) Train technicians for customers.
(4) The company sends engineering and technical personnel to the user site to plan the site and design the best process and plan for the user.

Sale:
(1) Acceptance of products.
(2) Assist customers in formulating construction plans.

After sale:
(1) Freely assign special after-sales service personnel to arrive at the scene to guide customers to install and debug.
(2) Equipment installation and commissioning.
(3) On-site training operators.
(4) After the installation of the complete set of equipment, 1-2 full-time technicians will be provided to assist the customer on-site production free of charge until the user is satisfied.
