Automatic cement block making machines are machines designed to produce cement blocks or bricks automatically, using raw materials such as cement, sand, gravel, and water. These machines are equipped with a PLC control system that allows them to operate automatically and produce high-quality blocks or bricks consistently.
Automatic cement block making machines are machines designed to produce cement blocks or bricks automatically, using raw materials such as cement, sand, gravel, and water. These machines are equipped with a PLC control system that allows them to operate automatically and produce high-quality blocks or bricks consistently.
The machines are designed to compress the raw materials using hydraulic pressure, which ensures that the blocks or bricks are compact, strong, and durable. They can produce different types of blocks or bricks, including solid blocks, hollow blocks, and interlocking blocks.
Automatic cement block making machines come in different sizes and models, with varying production capacities and automation levels. Some machines can produce up to 12,000 blocks or bricks per day, while others can produce up to 30,000 blocks or bricks per day.
These machines are widely used in construction projects, such as building walls, fences, and other structures. They are highly efficient and easy to operate, making them a popular choice for many users. Additionally, they have a low maintenance cost and are designed to last for many years, offering businesses a reliable and profitable investment.
For Automatic Cement Block Making Machine we have adopted hydraulic configuration, digital intelligent control, micro-operation, high degree of automation, convenient operation, stable mechanical performance, power saving, labor saving, high pressure and high output.
Automatic Cement Block Making Machine Uses: Production of various external wall blocks, interior wall blocks, flower wall blocks, floor slabs, berm blocks, interlocking blocks, curbs and other blocks. Adding face mix section to produce colored pavers.
Automatic Cement Block Making Machine Main raw materials: river sand (without soil), rice stone, stone powder, slag, construction waste (can be selected according to local resources), fly ash, cement, river sand, sea sand, mountain sand, mineral powder, slag, stone powder , coal slag, coal gangue, tailings slag, chemical slag, etc.
Automatic Cement Block Making Machine Technical Specification:
Dimension
5400×1960×3050mm
Weight
10.2T
Pallet size
1100 ×680mm
Power
42.15 kW
Vibration method
Siemens motors
Vibration Frequency
3800-4500 r/min
Cycle time
15-20s
Vibration Force
50-70KN
Equipments for basic concrete block making plant:
Items
Name of goods
Quantity
Note
1
Batching machine
1 set
OLI-WOLONG Vibrator
2
Concrete mixer
1 set
3
Belt conveyor
1 set
4
Material feeder
1 set
5
Block machine
1 set
One mould for free
6
Block/pallets conveyor
1 set
7
Automatic stacker
1 set
8
Hydraulic system
1 set
9
Electric cabinet
1 set
10
Pallets
1000 pcs
Various specifications and models can be customized according to customer requirements
Automatic Cement Block Making Machine Main features:
1. Excellent design: the mold operation adopts four-bar guiding mode, with the ultra-long copper sleeve to ensure the precise movement of the indenter and the mold box; the balance system consisting of the rack, the gear and the balance shaft ensures the balance between the indenter and the mold box. Degree and coordination degree; the parallel bar arm walking mode improves the running speed of the cloth machine, and the rotating convection forced cloth mode shortens the cloth time and ensures the compactness of the product.
2. The mold adopts various heat treatment processes such as quenching, tempering, carburizing, boronizing, etc., which greatly enhances the wear resistance of the mold and improves the life of the mold.
3. The hydraulic system adopts high dynamic proportional valve. The flow rate is automatically adjusted during the re-production process to protect the oil cylinder, so that the oil cylinder advances and retreats the end point to cushion, thereby improving the stability, prolonging the service life of the cylinder and improving the speed and flexibility of each part.
4. Vibration system: Adopting German frequency conversion technology, the main engine frequency conversion control, the vibration exciter assembly adopts oil immersion type, which improves the high-speed running load, so that the concrete is fully liquefied and exhausted instantaneously. The life of the bearing has more than doubled. The effect fully embodies the five advantages of the synchronization, soft start function of the vibrator assembly, the improvement of product compactness, more power saving and fast forming.
5. High degree of automation: The product has high degree of automation and advanced process design. It adopts international advanced high-tech microcomputer control technology to integrate mechanical main body and electrical equipment. Researchers use safety logic control to diagnose faults and text alarms. When many functions are added to the microcomputer, when the machine malfunctions, it can inform the user of the cause of the fault and the processing method in a timely and accurate manner.
6. System stability and safety: It is manufactured by strong and weak separation and weak electric control strong electric design principle. This can not only cancel the external interference of strong electricity but also ensure accurate signal acquisition, and also ensure the safety of people and equipment. The hydraulic system adopts the oil-immersed electromagnetic action design to reduce the oil temperature and improve the life while reducing the impact and ensuring the system stability.
Specification of products(mm)
Number of blocks per pallet
Pieces/1 hour
Pieces/8hours
Block
400×200×200
8
1,440
11,520
Hollow Brick
240×115×90
21
3,780
30,240
Paving Brick
225×112.5×60
20
4800
38,400
Standard Brick
240×115×53
42
10,080
80,640
Rectangular Paver
200×100×60/80
27
6,480
51,840
Service,delivery and shipping:
Before sales:
1. Provide our customers excellent technical advisory and deploy the most useful equipment along with production line according to the requirement of theirs
2. Provide technical data, including equipment listings, layout and installation instructions as well as a list of electricity demand for reference.
3. Assist in planning construction site, building plant and designing the best installation flow with our senior engineer
4. Design and manufacture product according to customers’ need
During sales:
1. Manufacture product in strict accordance with the relevant technical standards and constructional safety and healthy regulations
2. Advanced antirust preventives handling and then surface painting service
3. Products rigorous testing before shipment
4. Shipment arrangement by the contract in time
After sales
1. Dispatch the experienced engineers to assist in installation, machine test run and adjustment according to site conditions
2. Personnel training in operation and maintenance of the equipment on site guidance of waste recycling and sorting
3. Take initiative to eliminate the troubles rapidly at site
4. Prepare fully supply of wear parts and consumables for replacement
5. Maintenance for big items, our company guarantees to reach site after one call, ensure customer’s normal production
6. Optimizing machine and plant performance
7. Technical exchanging
The block making machine is packed in PVC film to Waterproof and dustproof, the spare parts will be packed in wooden case,This way of packing can ensure the machines will not shift inside the case and guarantee its security in transportation.
We will deliver concrete block making machine within 20-25 days after receiving deposit
