Automation Concrete Block Machine

Automation Concrete Block Machine is an efficient and intelligent concrete brick machinery and equipment. The equipment adopts advanced automation technology and PLC electrical control system, which can realize the automatic production of concrete bricks without too much manual intervention. During the production process, the concrete material is put into a machine and compressed into bricks of various shapes and sizes through a series of processes such as vibration, pressure and extrusion. Automation Concrete Block Machine is one of the indispensable equipment in the production process of modern construction engineering due to its high speed, high efficiency, high quality and high reliability. It can be used in residential buildings, public buildings, roads, underground facilities and other fields.

Automation Concrete Block Machine

Products Description

Automation Concrete Block Machine is an efficient and intelligent concrete brick machinery and equipment. The equipment adopts advanced automation technology and PLC electrical control system, which can realize the automatic production of concrete bricks without too much manual intervention. During the production process, the concrete material is put into a machine and compressed into bricks of various shapes and sizes through a series of processes such as vibration, pressure and extrusion. Automation Concrete Block Machine is one of the indispensable equipment in the production process of modern construction engineering due to its high speed, high efficiency, high quality and high reliability. It can be used in residential buildings, public buildings, roads, underground facilities and other fields.

A Automation Concrete Block Machine is a device used to produce concrete blocks that have hollow cores. These blocks are a popular building material in construction because they are strong, durable, and can be produced in different sizes and shapes. The machines used to produce these blocks use hydraulic pressure and vibration to create solid and hollow blocks in various sizes. The blocks are made from natural resources such as sand, cement, and water, are energy-efficient, and have a long lifespan. They can also be recycled, making them an environmentally friendly alternative to traditional building materials. According to different molds, the shape can be pressed into standard bricks, perforated bricks, blind-hole bricks, hollow blocks, interlock pavers and bricks with special requirements; according to the later curing process, it can be divided into natural curing non-burning bricks and steam-cured steamed bricks ( Autoclaved brick),block making is a critical process in construction. The quality of the blocks depends on the quality of the materials used in their production, the mixing process, and the curing process. To ensure that the blocks are of high quality, it is essential to use the right materials and follow the proper process for their production. With the right materials and process, blocks can be produced that are strong, durable, and effective in construction.



Automation Concrete Block Machine Technical Specification:

Dimension

3000 ×1900 ×2930mm

Weight

8.5T

Pallet size

1100 ×680mm

Power

42.15 kW

Vibration method

Siemens motors

Vibration Frequency

3800-4500 r/min

Cycle time

15-20s

Vibration Force

50-70KN



Block making process

Concrete Block Machine Price

Equipments for basic concrete block making plant:

Items

Name of goods

Quantity

Note

1

Batching machine

1 set

OLI-WOLONG Vibrator

2

Concrete mixer

1 set



3

Belt conveyor

1 set



4

Material feeder

1 set



5

Block machine

1 set

One mould for free

6

Block/pallets conveyor

1 set



7

Automatic stacker

1 set



8

Hydraulic system

1 set



9

Electric cabinet

1 set



10

Pallets

1000 pcs



Various specifications and models can be customized according to customer requirements

The process of block making begins with the selection of the right materials. The quality of the block depends on the quality of the materials used in its production. The most commonly used materials in block making are cement, sand, and water. Cement is the binding agent used to hold the blocks together. It is made from limestone, clay, and other minerals. Sand is used to provide bulk and strength to the blocks. Water is added to the mix to form a paste that can be poured into molds.

The next step is the mixing of the materials. A mixer is used to combine the cement, sand, and water to form a paste. The mixer is designed to ensure that the materials are evenly mixed. The mixer also helps to prevent the formation of lumps in the paste, which can cause defects in the blocks.

Once the paste is formed, it is poured into molds. The molds are made of metal or plastic and are designed to be filled with the paste. The molds come in different sizes, and the size of the mold used depends on the size of the blocks needed. The blocks can be made in different shapes, including rectangular, square, or even circular.

Once the molds are filled, they are left to set and harden. The time required for the blocks to set depends on the type of cement used and the ambient conditions. In general, the blocks should be left to set for at least 24 hours.

After the blocks have set, they are removed from the molds. The blocks are then cured, which involves keeping them in a damp environment for several days. The curing process helps to strengthen the blocks and reduce the risk of cracking.

The final step in the block making process is the packing and transportation of the blocks. The blocks are packed into bundles and loaded onto trucks for transportation to the construction site. The blocks are typically loaded onto pallets, which help to protect them during transportation.



Automation Concrete Block Machine Main features:

Concrete Block Machine Price

1.Four-column guide, patented extended guide sleeve for a more rugged construction.

2.The feeder adopts four-axis synchronous stirring to reduce the filling time and thus increase the brick making speed.

3.The forced mold synchronization structure ensures consistent product thickness, smooth demolding and high yield.

4.Vibration system can be optionally driven by hydraulic motor or SIEMENS servo motor

5.Big capacity with various types of concrete products. Equip with top color feeding system,it can produce color paving stone, also customizable according to different requirement, the max. Height of product can be made is 400mm



Products

Pic

Size

Capacity

Cycle time

Daily capacity

Hollow block

Concrete Block Machine Price

390 ×190 ×190mm

5pcs/pallet

15-20s

7200pcs

Hollow brick

Concrete Block Machine Price

240 ×115 ×90mm

16pcs/pallet

15-20s

23040pcs

Brick

Concrete Block Machine Price

240 ×115 ×53mm

34pcs/pallet

15-20s

48960pcs

Paver

Concrete Block Machine Price

200 ×100 ×60mm

20pcs/pallet

15-20s



28800 pcs

Concrete Block Machine Price

service,delivery and shipping:



Concrete Block Machine Price

We will deliver concrete block machine within 25-30 days after receiving deposit,The block making machine is packed in PVC film to Waterproof and dustproof, the spare parts will be packed in wooden case,This way of packing can ensure the machines will not shift inside the case and guarantee its security in transportation.

Our service:
Before sales:

1. Provide our customers excellent technical advisory and deploy the most useful equipment along with production line according to the requirement of theirs

2. Provide technical data, including equipment listings, layout and installation instructions as well as a list of electricity demand for reference.

3. Assist in planning construction site, building plant and designing the best installation flow with our senior engineer

4. Design and manufacture product according to customers’need
During sales:

1. Manufacture product in strict accordance with the relevant technical standards and constructional safety and healthy regulations

2. Advanced antirust preventives handling and then surface painting service

3. Products rigorous testing before shipment

4. Shipment arrangement by the contract in time
After sales

1. Dispatch the experienced engineers to assist in installation, machine test run and adjustment according to site conditions

2. Personnel training in operation and maintenance of the equipment on site guidance of waste recycling and sorting

3. Take initiative to eliminate the troubles rapidly at site

4. Prepare fully supply of wear parts and consumables for replacement

5. Maintenance for big items, our company guarantees to reach site after one call, ensure customer’s normal production

6. Optimizing machine and plant performance

7. Technical exchanging
