Paver Block Manufacturing Machine

Paver Block Manufacturing Machine

Paver block manufacturing machines are used in the construction industry for producing concrete interlocking paving blocks, bricks, tiles, and curbs. These machines are designed to take the raw materials like cement, sand, fly ash, water, and other aggregates, and create finished products that are uniform in size, shape, and quality.

Paver Block Manufacturing Machine

Paver Block Manufacturing Machine is composed of several parts, including the main machine, hydraulic station, conveyor blet, mixer, board feeding machine, board discharge machine, block conveyor machine etc., our block machine has multi powerful functions, reliable quality in the production of paver blocs, and reliable production.


Paver block manufacturing machines are used in the construction industry for producing concrete interlocking paving blocks, bricks, tiles, and curbs. These machines are designed to take the raw materials like cement, sand, fly ash, water, and other aggregates, and create finished products that are uniform in size, shape, and quality.

Paver block manufacturing machines come in a variety of types and sizes, ranging from manual machines operated by hand to fully automatic machines that operate with minimal human intervention. The machines can produce a range of products from very simple straight paving blocks to more complex interlocking designs.

Some of the key features and benefits of paver block manufacturing machines include fast production times, high precision and accuracy, low maintenance requirements, and reduced labor costs. They are also highly customizable, allowing users to create unique designs and textures for their paving projects.


Main Features:



Paver Block Manufacturing Machine

Paver Block Manufacturing Machine



Siemens control system, four-axis synchronous patented vibration system, the machine is stable and easy to operate The forced synchronous vibration system of the forming machine can adjust the vibration excitation force through frequency conversion technology, use rigid transmission, no kinetic energy loss and can ensure accurate synchronization, less energy consumption, and better excitation effect.

Paver Block Manufacturing Machine



Paver Block Manufacturing Machine



Siemens motor :high efficiency levels reduce energy consumption, directly enabling users to save costs



The special rotating arch-broken feeding and horizontal grid mechanism can choose different cloth mechanisms according to different products.



Paver Block Manufacturing Machine Technical Specifications:



Dimension

3280×1950×3250mm

Pallet Size

850×680×20mm

Vibration Frequency

3800-4500 r/min

Hydraulic Pressure

25 mpa

Vibration Force

68 KN

Cycle time

15-20s

Power

38.45kW

Weight

7400KG

Product size(mm)

Pcs./Pallet

Pcs./Hour

390x190x190mm Paver Block Manufacturing Machine

6

1080

240x115x90mm Paver Block Manufacturing Machine

15

3600

200x100x60mm Paver Block Manufacturing Machine

21

3024

240x115x53mm Paver Block Manufacturing Machine

30

7200


Paver Block Manufacturing Machine

 Service, Delivery and shipping:

Unik has high-quality technical services team, is able to achieve a rapid response, customer feedback, technical advice, staff training, long-term provision of spare parts supply, to ensure premium services at any time.

The Paver Block Manufacturing Machine is packed in PVC film to Waterproof and dustproof, the spare parts will be packed in wooden case,This way of packing can ensure the machines will not shift inside the case and guarantee its security in transportation.

We will deliver the orderded baking-free brick machine 20-25 days after receiving deposit.

Our company has established a strict quality control system from design, manufacturing, sales, testing and after-sales service, and has a nationwide sales network to provide users with the highest quality products and the most satisfactory services.Over the years, the company has won wide acclaim from users and all walks of life with advanced technology, high-quality products and good service.
