Automatic block making machines are machines that are used to produce concrete blocks with the help of molds and by applying pressure. These machines are also known as concrete block machines, brick making machines, or cement block machines. They reduce the manual efforts that are needed for making concrete blocks, thus increasing the production rate and saving time.
Automatic block making machines are machines that are used to produce concrete blocks with the help of molds and by applying pressure. These machines are also known as concrete block machines, brick making machines, or cement block machines. They reduce the manual efforts that are needed for making concrete blocks, thus increasing the production rate and saving time.
The equipment includes a conveyor belt, mixer, block machine, hydraulic station, and palletizer. Different sizes and shapes of blocks can be produced by changing the molds of the machine. The process involves pouring cement, water, and other aggregates into the mixer where they are mixed together. The mixed ingredients are then poured into the block-making machine's mold where they are compacted and shaped.
Once the blocks are formed, they are pushed out of the mold and onto the conveyor belt. The palletizer then lifts the blocks onto a pallet where they are left to cure. With advanced automation features, these machines have greatly improved production speed and quality control, making them very popular in the construction industry.
Automatic Block Making Machines are used to make paving blocks of different shapes and sizes. They are typically automatic machines consisting of batch hopper, a vibrating table, a mold, and a calibrating tabular. The batch hopper is used to load and measure the amount of raw materials required for the production and to feed it into the vibrating table. The vibrating table also aids in packing the mix and helps to give a compacted surface finish. The mold is used to form the blocks which are then taken out of the mold onto the calibrating tabular which is used to cut and shape the blocks. The manufacturing process of paving blocks requires sand, cement, aggregate and water. Concrete blocks are then formed in the vibrating table and are laid on the surface for the final look.
Main structure and technical features:
1. With the unique hydraulic and auxiliary systems, the compactness and strength of the products produced by using the equipment are greatly improved.
2. The equipment is controlled by a fully automatic PLC computer system. The PLC is imported from Japan, and Japan's technology has been used in automatic control programs to make great adjustments to the previous equipment, so that the stability of the equipment program is perfect.
3. Electrical components of control system use international famous brands such as Omron, Siemens, ABB, etc.This is to ensure the stability of the control system, and the system operating parameters can be modified and set by touch screen.
4. It has compact structure, simple operation,easy maintenance, stable and reliable,small floor space, economical and practical, suitable for small and medium-sized customers to start investment.
5. Due to the stability of the equipment and the low failure rate, the cost of maintenance and replacement of parts during use is reduced, unnecessary maintenance time is eliminated, production efficiency is increased.
6.The mold structure: the replacement of mold is simple and convenient. Electromechanical hydraulic drive synchronously, the error of same pallets is minimal, and the intercommunity of product is excellent.
Automatic Block Making Machines Technical specification:
Dimension
3280×1950×3250mm
Pallet Size
850×680×20mm
Vibration Frequency
3800-4500 r/min
Hydraulic Pressure
25 mpa
Vibration Force
68 KN
Cycle time
15-20s
Power
38.45kW
Weight
7400KG
Automatic Block Making Machines Capacity:
The capacity of an automatic block making machine determines the amount of blocks that can be produced within a specified period. The higher the capacity, the more the machine can produce, translating to a higher price tag. It is essential to note that investing in a machine with higher capacity may initially cost more, but in the long run, it can result in lower production costs per block, therefore, more savings.
Automatic Block Making Machines have revolutionized construction in many parts of the world today. By automating the process of producing blocks, these machines have simplified the construction process and increased productivity. Automated block making machines have gained popularity in recent times, and the demand for them has risen significantly. However, with demand comes the need to deliver these machines to their users.Steel equipments including main machine, stacker, block/pallet conveyor, mixer and batching machine ect, will be packed by wrapping film in the container according to the space of container. The electrical components and other small items will be packed in strong seaworthy wood cases.
Our service:
Pre-sale service
◆ Accept consultation
◆ Confirm user investment target
◆ Site selection
◆ Design and construction plan, drawings
Sale service
◆ Assist in the supervision of the construction process
◆ Provide on-site guidance installation, commissioning equipment
◆ Help users establish on-site management system and quality management system
◆ Training production operators
After sales service
◆ Assist users in formulating production process recipes
◆ Provide network remote service
◆ Technician on-site maintenance
◆ Safe and fast parts distribution
Additional service:
◆Equipment mold update
◆Technical update, system upgrade
◆Product application technical support
◆Share the latest results
