Hollow block brick making machine is a machine used for the production of hollow concrete blocks. The machine uses vibration and hydraulic pressure to produce high-quality and durable concrete blocks of different sizes and shapes. The hollow block brick making machine comes with different molds that can be changed to produce different types of blocks, including solid blocks, hollow blocks, interlocking blocks, and paving blocks. The machine has a high production capacity and can produce thousands of blocks in a short time, making it ideal for large-scale construction projects. It is an essential machine in the construction industry and is widely used in the production of walls, partitions, and other building components.
Hollow block brick making machine is a machine used for the production of hollow concrete blocks. The machine uses vibration and hydraulic pressure to produce high-quality and durable concrete blocks of different sizes and shapes. The hollow block brick making machine comes with different molds that can be changed to produce different types of blocks, including solid blocks, hollow blocks, interlocking blocks, and paving blocks. The machine has a high production capacity and can produce thousands of blocks in a short time, making it ideal for large-scale construction projects. It is an essential machine in the construction industry and is widely used in the production of walls, partitions, and other building components.
Products Description
Hollow block brick making machines have been introduced to the construction industry as an efficient way of producing high-quality bricks and blocks for building construction. These machines have proven to be very effective and reliable in producing hollow bricks with the required level of precision and consistency.Hollow block machines are designed to make hollow blocks, bricks or paving blocks with suitable molds. They are highly automated machines that are capable of producing a large number of bricks in a short time. They are used in various construction projects such as residential and commercial buildings, as well as for landscaping projects.
Main technical features:
1.Hydraulic pressure: Imported hydraulic components and seals are used, and high dynamic performance proportional valves are used to adjust the oil volume and pressure according to different work requirements to control the movement of key components.
2.Control: Industrial PLC control system is adopted, with Chinese display, touch operation, stepless frequency modulation and variable speed, and the action can be changed at any time according to different raw materials, which is very flexible.
3.Fabrication: The unique crank-connecting rod structure and forced unloading device completely solve the problem of special-shaped bricks’ distribution, and the secondary distribution can produce various colored pavement bricks.
4.Mold: Increased thickness, fine grinding, special steel, high-frequency carburizing treatment, mold box gusset without welding, longer life. It adopts plug-in design, which can be replaced in a few minutes, realizing one machine with multiple functions.
5.Anti-vibration: The unique capsule shock-absorbing technology can more effectively prolong the life of the machine body and mold box under large excitation force.
Technical specifications:
Dimension
3280×1950×3250mm
Pallet Size
700×540×20mm
Vibration Frequency
3800-4500 r/min
Hydraulic Pressure
25 mpa
Vibration Force
68 KN
Cycle time
15-20s
Power
20.55kW
Weight
5500KG
Multi-purpose automatic pavement brick machine production line can produce different specifications of porous brick, hollow block, curb stone, pavement brick, grass planting brick, slope protection brick and other cement products by replacing brick machine mold. The output table is as follows:
Product size(mm)
Pcs./Pallet
Pcs./Hour
390x190x190mm
3
540
240x115x90mm
10
2400
200x100x60mm
12
2880
240x115x53mm
20
4800
Hollow brick block machines have become essential in modern construction. They offer a faster, more efficient, and more cost-effective way of producing high-quality construction materials. By using these machines, builders can deliver their projects faster and with more precision, ensuring customer satisfaction in the end.
Hollow brick block making machines are environmentally friendly. They use less cement and thus produce fewer carbon emissions compared to traditional brick-making methods. These machines also minimize the waste produced, as any unused materials can be recycled and reused.The use of hollow brick block machines has revolutionized the construction industry. These machines have become an essential part of the construction process, offering a faster, more efficient, and more cost-effective way of producing high-quality construction materials. With the continued improvement of technology, hollow brick block machines will continue to play a crucial role in modern construction.In Philippines market, we have more experience and helped many customers to made deep customized designs about hollow block. If you require special design hollow block please email us sales@unikmachinery.com
