Hollow paving block making machine is a type of equipment used for the production of hollow concrete blocks used for paving and landscaping. The machine is designed to produce blocks with a hollow core, which makes them lightweight and easy to handle. The blocks have a unique interlocking design that allows them to fit perfectly together, creating a smooth and even surface for sidewalks, driveways, and other outdoor spaces.
The machine works by mixing cement, sand, and water in a batch mixer and then pouring the mixture into a mold. The mold is then compressed by the machine, which applies pressure and vibration to the mixture, shaping it into the desired block shape. Once the blocks are formed, they are removed from the mold and left to cure for a specified period.
Hollow paving block making machines come in various sizes and configurations to suit different production needs. Some machines are fully automated, while others require some manual input. They are widely used in the construction industry to produce high-quality and durable blocks that can withstand harsh weather conditions and heavy traffic.
Our Hollow Paving Block Making Machine are built to last. We use top-notch materials and pay close attention to every little detail. Whether it's the welding on the frame or the precision of the parts, we don't cut corners. We want to ensure that when you invest in our brick machine, you're getting something that will work hard for you for years to come.We also keep our production process pretty flexible. If you've got a specific need or a custom order, just let us know. We're here to work with you to make sure you get exactly what you want.
1
We're committed to producing brick machines that are configured with the highest standards. Our machines are recognized for their superior performance and reliability, which is something we take great pride in
2
Even though we're not the largest, our brick machines are configured to be among the best in the industry. We use top-quality components and continuously upgrade our technology to ensure our machines stay ahead of the curve
3
One thing that sets us apart is our dedication to constant improvement. We're always refining and perfecting our equipment based on user feedback. If there's an issue or a way to make our machines even better, we're on it
4
Our machines are designed to be adaptable. Whether you need a standard model or something custom, we can work with you to make sure you get the brick machine that fits your specific requirements
When mixing and loading cement brick machines, attention should be paid to the fact that the mixed materials should not contain coarse aggregates or other foreign and hard objects, especially solid objects such as steel, to avoid damage to mechanical parts. The block machine is combined with new technical support, and the driving force can achieve the production of various high-strength load-bearing blocks and non-load-bearing blocks. The cement block machine equipment can realize the automation process by combining mixers, conveyors, batching machines, stacking machines, etc., and can produce various blocks and porous bricks. It can also be equipped with a layered feeder to complete smooth or colored floor tiles, curb stones, etc.
|
Specification of products(mm) |
Number of blocks per pallet |
Pieces/1 hour |
Pieces/8hours |
||
|
Block |
|
400×200×200mm |
10 |
1,800 |
14,400 |
|
Hollow Brick |
|
240×115×90mm |
25 |
6,000 |
48,000 |
|
Paving Brick |
|
225×112.5×60mm |
25 |
6,000 |
48,000 |
|
Standard Brick |
|
240×115×53mm |
55 |
13,200 |
105,600 |
|
Curbstone |
|
200*300*600mm |
4 |
720 |
3,840 |
|
Dimension |
3100 ×1930×3700mm |
|
Weight |
11.5T |
|
Pallet size |
900×900mm |
|
Power |
49.03 kW |
|
Vibration method |
Servo motors |
|
Vibration Frequency |
3800-4500 r/min |
|
Cycle time |
15-20s |
|
Vibration Force |
75KN |
Manufacturing
Delivery
workshop
Process
Our company has always adhered to the development direction of energy saving, emission reduction, recycling, and intelligent innovation, and has continuously launched high-end environmental protection building materials and complete sets of equipment that meet the needs of social development, and continue to help the development of ecological environmental protection and solid waste resource recycling. So far, UNIK has successfully implemented more than 500 environmental protection block factories landing projects at home and abroad, and its product quality and technical standards have obtained High praise from customers at home and abroad.
Our service:
Pre-sale service
◆ Accept consultation
◆ Confirm user investment target
◆ Site selection
◆ Design and construction plan, drawings
Sale service
◆ Assist in the supervision of the construction process
◆ Provide on-site guidance on installation, commissioning equipment
◆ Help users establish an on-site management system and quality management system
◆ Training production operators
After-sales service
◆ Assist users in formulating production process recipes
◆ Provide network remote service
◆ Technician on-site maintenance
◆ Safe and fast parts distribution
Additional service:
◆Equipment mold update
◆Technical update, system upgrade
◆Product application technical support
◆Share the latest results
