Hollow brick production machinery is a machine that is used to manufacture hollow bricks. These bricks have hollow spaces in the middle, which makes them lighter and more efficient in terms of material usage.
The machinery includes a series of equipment such as a mixer, conveyor belt, raw material feeder, hydraulic press, and kiln. This equipment works together to mix raw materials such as clay, shale, or fly ash with water and form them into bricks.
The bricks are then dried and fired in the kiln to increase their strength and durability. The machinery can produce different sizes and shapes of hollow bricks according to the requirement of the user.
Hollow brick production machinery is widely used in the construction industry as hollow bricks are considered to be an efficient and cost-effective building material.
Hollow brick production machinery is a machine that is used to manufacture hollow bricks. These bricks have hollow spaces in the middle, which makes them lighter and more efficient in terms of material usage.
The machinery includes a series of equipment such as a mixer, conveyor belt, raw material feeder, hydraulic press, and kiln. This equipment works together to mix raw materials such as clay, shale, or fly ash with water and form them into bricks.
The bricks are then dried and fired in the kiln to increase their strength and durability. The machinery can produce different sizes and shapes of hollow bricks according to the requirement of the user.
Hollow brick production machinery is widely used in the construction industry as hollow bricks are considered to be an efficient and cost-effective building material.
It has the features of compact structure, easy operation, convenient maintenance, reliable economical and practical, suitable for those investors who are in small or medium scale.
1) Simplified hydraulic system, workers can handle the operation easily
2) Simple horizontal secondary material feeding, combine both pressing and vibrating, ensure the high compactness and performance
3) Twin electric motor forming, saves the time and money
4) Compact structure, easy operation, convenient maintenance, solid and reliable, suitable for customers start the investment.
Main features:
★ Imported Omron PLC program control
★ Intelligent touch screen
★Touch operation
★ Hydraulic system drive
★ Frequency Siemens motor vibration
★ Non-contact proximity switch monitoring
★Remote control
★ A multi-function machine
The frame adopts structural steel and special welding technology, which is sturdy and reliable, ensuring the rigidity and shock resistance of the equipment
It adopts multi-source vibration system, which is suitable for large work surface, integrates multiple technologies such as computer control, hydraulic drive, electromechanical synchronization, etc., adopts fully synchronous vibration mode, adjustable vibration force, frequency can be adjusted according to different process requirements, low frequency feeding, High frequency molding.
Raw materials for production: use crushed stone powder, sand, stones, cement, and a variety of industrial wastes such as fly ash, slag, steel slag, coal gangue, ceramsite, and perlite can be added in large quantities.
Capacity:
Product size
Capacity
390×190×190(mm)
6 pcs/pallet 1100-1500pcs/hour
240×115×53(mm)
40 pcs/pallet 8000-9000pcs/hour
198×98×60/80(mm)
27 pcs/pallet 4400-4800pcs/hour
447×298×80/100(mm)
4 pcs/pallet 600-700pcs/hour
Pallet size
1100×670㎜
Vibration type
Frequency, amplitude
Excitation frequency
0~65HZ
Power
42.15 kW
Our Service:
Before sale:
(1) Selection of equipment model.
(2) Design and manufacture products according to customers' special requirements.
(3) Train technical personnel for customers.
(4) The company sends engineering and technical personnel to the user site for free to plan the site and design the best process and plan for the user.
On sale:
(1) Product acceptance.
(2) Assist customers in drawing up construction plans.
After sale:
(1) Freely assign dedicated after-sales service personnel to arrive on site to guide customers in installation and commissioning.
(2) Equipment installation and debugging.
(3) On-site training of operators.
(4) After the complete set of equipment is installed, 1-2 full-time technicians will be left to assist the customer in on-site production for free until the customer is satisfied.
Our company has consistently adhered to the business philosophy of integrity, pragmatism and innovation as well as the principle of seeking truth from facts.
We insist on a responsible and trustworthy attitude, treat the user's success as our business goals. Taking the users’ satisfaction as our service tenet,
we will try our best to provide the users the products with high quality, competitive prices. excellent, thoughtful and fast service.
Hot Tags: Hollow brick production machinery, China, Manufacturer, Supplier, Factory
