Hydraulic Hollow Block Machine is a type of construction machinery that is used to produce hollow concrete blocks for various purposes such as building walls, pavements, and other structures.
Hydraulic Hollow Block Machine is a type of construction machinery that is used to produce hollow concrete blocks for various purposes such as building walls, pavements, and other structures.
The machine uses hydraulic pressure to compress the raw materials such as cement, sand, and water into hollow blocks of different sizes and shapes. The blocks can be further processed by painting, decorating, or other methods of finishing, depending on the specific needs of the project.
The Hydraulic Hollow Block Machine can come in different models, each with varying capacities and capabilities. Some models can produce up to 20 blocks per minute, while others can produce up to 50 blocks per minute.
These machines are generally used in large-scale construction projects such as building roads, bridges, and commercial buildings. They can also be used by individual contractors or small construction firms for producing custom blocks for smaller projects.
Hydraulic hollow block machine is the environmental protection wall material processing equipment in line with national industrial policy and advocated by the national new wall materials reform. It is designed and produced through the continuous innovation and improvement of our factory and staff (Modification of characteristics: from the cross out of the brick to a word out of brick, thereby increasing the yield and the one-time-forming changed from ten to twelve). After nearly 3 years' actual use, whether from the yield or from the stability of the equipment, molding time of this equipment has been greatly improved than the previous 3-type machine. It is also have obvious advantages when relative to similar products of other manufacturers.
Technical Specification:
Dimension
2710×1400×2300 mm
Pallet Size
700×540×20mm
Vibration Frequency
3800-4500 r/min
Hydraulic Pressure
25 mpa
Vibration Force
68 KN
Cycle time
15-20s
Power
20.55kW
Weight
5500 KG
Capacity
Product size (mm)
Pcs./Pallet
Pcs./Hour
390*190*190
3
540
390*140*190
4
720
200*100*60
10
1440
225*112.5*60
10
1440
Main features:
1. The whole machine is made of steel and precision welding. The hydraulic system adopts Taiwan hydraulic components, which has durability and greatly improves the continuous failure of the whole machine. The work rate is high and the machine has a long service life.
2. The machine has low price, high quality, large technical content, simple operation, stable operation, fast production speed, high output and low power consumption (power consumption is only one-sixth of that of similar production models). The produced blocks have high density, high strength, accurate size and flat appearance. The selection of this machine can greatly reduce the investment and production cost of customers.
3. The main raw materials are stone, stone nitrate, stone powder, yellow sand, coal gangue, slag, fly ash, construction waste, ore dressing tailings, suitable for mountainous areas, hilly areas, industrial plant mining areas, clay control areas, urban suburbs. In areas such as deserts and coastal areas, the equipment is suitable for individual production and operation.
Service,delivery and shipping:
Unik has high-quality technical services team, is able to achieve a rapid response, customer feedback, technical advice, staff training, long-term provision of spare parts supply, to ensure premium services at any time.
Before sale:
(1) The selection of equipment model.
(2) According to the special requirements of customers, design and manufacture the products.
(3) Training of technical staff for clients.
(4) The company can be free to plan venue for customers and design best programs.
In-sale:
(1) The acceptance of products.
(2) Assisting clients in formulating construction plans.
After sale:
(1) Free assigned special service personnel, arrived at the scene to guide customer installation and commissioning.
(2) The installation and commissioning of equipment .
(3) The training of operators on-site.
The block making machine is packed in PVC film to Waterproof and dustproof, the spare parts will be packed in wooden case,This way of packing can ensure the machines will not shift inside the case and guarantee its security in transportation.
We will deliver the orderded baking-free brick machine 20-25 days after receiving deposit
